Tie Rod - Cylinders - Hydraulics

MFG

SKU

Description

Price

Advanced Cylinder

2004TR-ORB/NPT

2" BORE X 4" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2004TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 4" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2004TR-ORB/NPT
SKU	2004TR-ORB/NPT
Short Description	2" BORE X 4" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	4"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	14.25"

Advanced Cylinder

2010TR-ORB/NPT

2" BORE X 10" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2010TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 10" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2010TR-ORB/NPT
SKU	2010TR-ORB/NPT
Short Description	2" BORE X 10" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	10"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	20.25"

Advanced Cylinder

2016TR-ORB/NPT

2" BORE X 16" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2016TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 16" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2016TR-ORB/NPT
SKU	2016TR-ORB/NPT
Short Description	2" BORE X 16" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	16"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	26.25"

Advanced Cylinder

2018TR-ORB/NPT

2" BORE X 18" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2018TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 18" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2018TR-ORB/NPT
SKU	2018TR-ORB/NPT
Short Description	2" BORE X 18" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	18"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	28.25"

Advanced Cylinder

2506TR-ORB/NPT

2.5" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2506TR-ORB/NPT

Call for Pricing & Availability

2.5" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2506TR-ORB/NPT
SKU	2506TR-ORB/NPT
Short Description	2.5" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	6"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2.5"
Closed Dimension Pin to Pin	16.25"

Advanced Cylinder

2006TR-ORB/NPT

2" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2006TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2006TR-ORB/NPT
SKU	2006TR-ORB/NPT
Short Description	2" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	2" BORE X 6" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Catalog
Pin Diameter	1"
Stroke	6"
Rod Size	1.125"
Ports	SAE 8
Pressure Rating	2500
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	16.25

Advanced Cylinder

2008TR-AORB/NPT

2" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2008TR-AORB/NPT

Call for Pricing & Availability

2" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2008TR-AORB/NPT
SKU	2008TR-AORB/NPT
Short Description	2" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	8"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	20.25" (2" Rod Extension)

Advanced Cylinder

3008TR-AORB/NPT

3" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 1/2 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 3008TR-AORB/NPT

Call for Pricing & Availability

3" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 1/2 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	3008TR-AORB/NPT
SKU	3008TR-AORB/NPT
Short Description	3" BORE X 8" STROKE ASAE AG CYLINDER SAE 8 & 1/2 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	8"
Rod Size	1.25"
Ports	SAE 8 & 1/2" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	3"
Closed Dimension Pin to Pin	20.25" (2" Rod Extension)

Advanced Cylinder

2012TR-ORB/NPT

2" BORE X 12" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2012TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 12" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2012TR-ORB/NPT
SKU	2012TR-ORB/NPT
Short Description	2" BORE X 12" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	12"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	22.25"

Advanced Cylinder

2014TR-ORB/NPT

2" BORE X 14" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2014TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 14" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2014TR-ORB/NPT
SKU	2014TR-ORB/NPT
Short Description	2" BORE X 14" STROKE CYLINDER SAE 8 PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	14"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	24.25"

Advanced Cylinder

2020TR-ORB/NPT

2" BORE X 20" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2020TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 20" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2020TR-ORB/NPT
SKU	2020TR-ORB/NPT
Short Description	2" BORE X 20" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	20"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	30.25"

Advanced Cylinder

2024TR-ORB/NPT

2" BORE X 24" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Call for Pricing & Availability

DETAILS

In stock

SKU 2024TR-ORB/NPT

Call for Pricing & Availability

2" BORE X 24" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS

Specifications

More Information
Product Name	2024TR-ORB/NPT
SKU	2024TR-ORB/NPT
Short Description	2" BORE X 24" STROKE CYLINDER SAE 8 & 3/8 NPT PORTS W/ 1" CLEVIS PINS
Description	Tie Rod Cylinder
Catalog
Pin Diameter	1"
Stroke	24"
Rod Size	1.125"
Ports	SAE 8 & 3/8" NPT
Pressure Rating	2500 PSI
Manufacturer	Advanced Cylinder
bore_size	2"
Closed Dimension Pin to Pin	34.25"
